- General Information
- Manufacturer
- Vertiv
- Manufacturer Website Address
- http://www.vertiv.com/
- Brand Name
- Vertiv Geist
- Product Type
- PDU
The 38396 functions as a basic power strip without built-in surge protection. This unit is ideal for installations in facilities with proper surge protection at the main electrical service entrance.
- Warranty
- Limited Warranty
- 5 Year
- Technical Information
- PDU Type
- Basic
- Plug/Connector Type
- NEMA L6-20P
- Plug/Connector Detail
- 1 x NEMA L6-20P
- Receptacle Type
- NEMA 6-20R
- Receptacle Detail
- 20 x NEMA 6-20R
- Protection Type
- Overcurrent Protection
- Power Description
- Input Voltage
- 230 V AC
- Output Voltage
- 208 V AC
- Power Rating (Watt)
- 3300 W
- Input Current
- 20 A
- Physical Characteristics
- Mounting Orientation
- Vertical
- Mount Type
- Rack-mountable
- Rack Height
- 0U
- Width
- 1.9"
- Depth
- 1.3"
- Length
- 66.3"
- Miscellaneous
- Package Contents
- VHVBN202-102D20TL6 20-Outlets PDU
- Vertical Mounting Bracket Kit
- Country of Origin
- United States
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
